Details
Category 6 cable, commonly referred to as Cat.6, is a standardized cable for Gigabit Ethernet and other network physical layers that is backward compatible with the Category 5/5e and Category 3 cable standards. Compared with Cat.5 and Cat.5e, Cat.6 features more stringent specifications for crosstalk and system noise. The cable standard provides performance of up to 250 MHz and is suitable for 10BASE-T, 100BASE-TX (Fast Ethernet), 1000BASE-T/1000BASE-TX (Gigabit Ethernet) and 10GBASE-T (10-Gigabit Ethernet). No matter what the size of your networking project, SFPcables.com is here to help with a great selection of Cat.6 Ethernet cable in a variety of lengths and colors. All of our Cat.6 Ethernet cables work great with DSL and Cable modems, plus, they're built to work well with gigabit networks. Finally – a better Ethernet cable for your office.
- Cat.6 LAN Cable For Internet Connection
- Frequency: 250-350MHz
- FLUKE DPX-LT pass
- UTP/(FTP/SFTP for option)
- Transmission velocity: 1000Mbps
- Voice
- Fast Ethernet(IEEE802.3u)
- 100Vg-AnyLAN(IEEE 802.12)
- Token Ring(IEEE 802.5)
- TP-PMD(ANSI X3T9.5)
- 100Base-T Ethernet(IEEE 802.5)
- 155/622 Mbps 1.2/ 2.4 Gbps ATM
- 1000Base-T Ethernet
- 550 MHz Broadband Vedio
- ETL verified
- TIA/EIA 568-2
- ISO/IEC 11801
- EN 50173
- RoHS
Frequency MHz | Impedance ohm | RL dB | Attenuation dB/100m | NEXT dB/100m | ELFEXT dB/100m | PS NEXT dB/100m | PS ELFEXT dB/100m | Delay Skew Ns/100m |
1 | 100±15 | 20 | 1.9 | 74.3 | 67.8 | 72.3 | 64.8 | ≤45 |
4 | 23 | 3.7 | 65.3 | 55.8 | 63.3 | 57.7 | ||
8 | 25 | 5.3 | 60.3 | 49.7 | 58.8 | 46.7 | ||
10 | 25 | 5.9 | 59.3 | 47.8 | 57.3 | 44.8 | ||
16 | 25 | 7.5 | 56.3 | 43.7 | 54.3 | 40.7 | ||
20 | 25 | 8.4 | 54.8 | 41.8 | 52.8 | 38.7 | ||
25 | 24 | 9.5 | 53.4 | 39.8 | 51.4 | 36.8 | ||
31.25 | 24 | 10.6 | 51.9 | 37.9 | 49.9 | 34.9 | ||
62.5 | 22 | 15.4 | 47.4 | 31.9 | 45.4 | 28.8 | ||
100 | 21 | 19.8 | 44.3 | 27.8 | 42.3 | 24.8 | ||
155 | 21 | 25.1 | 41.5 | 23.9 | 39.5 | 20.9 | ||
200 | 21 | 29.0 | 39.8 | 21.8 | 37.8 | 18.7 | ||
250 | 18 | 32.8 | 38.3 | 19.8 | 36.3 | 16.8 |
Knowedge Base
What are Cat6 Ethernet Cables? Cat6 Ethernet cables are a higher-bandwidth version of Cat5e Ethernet Cables, which are the most commonly used networking cables.
Does this hook up my computer to my modem? Yes! You can use these cables to connect your computer, modem, or router. Most household networks and internet connection devices use Cat5e.
What does Cat6 mean? Cat6 is short for Category 6. Cat6 is the next level up from Cat5e.
What is the difference between Cat5e & Cat6? Cat6 is faster and is used for top of the line networks. While Cat6 will work just as well as Cat5e, the cables alone will not improve the speed of your network.
Will this make my internet connection faster? No; the cable alone will not make your connection faster, it only adds more bandwidth. Imagine that the cable is a highway: adding more bandwidth is like adding more lanes. It allows more traffic, but it doesn't make your car faster. To increase the speed of your internet connection, you must improve your network.
Can I use these cables for my Playstation, XBox or other gaming system? Yes. You can use either these cables or Cat5e patch cables.
Do these cables come with plugs on the ends? Yes. The cables on this page are pre-terminated so they are ready to use right out of the box.
Are these the same cables I would buy at my local electronics store? Yes! Our cables may not be the same brand that you would buy at a Radio Shack or Best Buy, but the cables perform the same and are tested in the same way.
Why do these cables cost so much less than cables at other stores? There are two main reasons. We only sell our cables on the Web so we do not have the expenses and overhead required to run a brick-and-mortar store. The second reason is that we manufacture our own cables. Brand-name cables are well-known for being overpriced, while our cables have the exact same technical specifications.
How are you patch cables measured? Our patch cables are measured from tip-to-tip. There is, however, a tolerance to be aware of. This tolerance is listed as (+ or –) in inches on the spec sheet for each product. For this cable the tolerance is between 5 - 7 inches.
